Automating SAP Transport Pipelines with GitLab & gCTS in 20 Minutes — A Deep Dive
By SAPSOL Technologies Inc.
1 ▸ Why DevOps for SAP Matters in 2025
In classic ECC landscapes, transports get hand‑carried from DEV to QA like royal scrolls while Basis admins cross fingers and bite nails. In 2025 that ritual is more than old‑school—it is an outright bottleneck. A four‑column spreadsheet and a shared folder cannot keep pace with feature‑pack drip releases, hot security notes, and scrappy start‑ups rolling updates ten times a day. SAP’s Git‑enabled Change and Transport System, gCTS, finally answers the age‑old question: “Why can’t SAP transports behave like a modern repo?”
Yet adoption stalls because teams fear complexity. This post demystifies gCTS end‑to‑end. We clone an ABAP package, push it to GitLab, wire a CI/CD pipeline, and deploy to QA—all in under twenty minutes of keyboard time. No proprietary A‑L‑M frameworks, no PowerPoint, no consulting oracle—just real commands and YAML you can copy‑paste.
Visit https://www.sapsol.com/free-sap-poc/ for a FREE Sap Poc within 24 hours.
2 ▸ Prerequisites at a Glance
Before jumping in, make sure you have:
- An S/4HANA 1909 or newer system (gCTS requires at least the basic Git client).
- An SAP user with S_DEVELOP and S_CTS_ADMI authorisations.
- A GitLab project with a Personal Access Token (PAT) granting api scope. GitHub or Bitbucket will work too, but today’s snippets target GitLab CI syntax.
- A service user in SAP for HTTP operations—call it GCTS_BOT—mapped to your GitLab token via OAuth or basic auth.
Time‑boxed? Keep reading anyway. The initial commit and webhook wiring take ten minutes. The rest can wait for your next coffee.
3 ▸ Setting Up gCTS Inside SAP
- Launch transaction SCTS_AM (gCTS App Manager). Click “Repositories” then “Create Repository.”
- Choose a name—ZSOL_DEMO works. Set Repository Type to GIT.
- Paste the HTTPS URL from GitLab and provide your PAT as the authentication.
- Tick “Automatic Pull” if you want nightly syncs. For now leave it unchecked; we will trigger pulls via pipeline later.
- Save. SAP spins up a local bare repo at /usr/sap/trans/git and auto‑creates a transport layer ZGS.
Tip: If the checkbox “Enable Repository” remains grey, your SAP Kernel lacks Git client libs. Cygwin‑style Git binaries live under usr/sap/<SID>/SYS/exe, but older patch levels omit them. Update or point DFGITBINprofile param to a system Git.
Now, any ABAP object assigned to layer ZGS appears in the Git view. But we want CI/CD, not manual pushes. Enter abapGit.
4 ▸ Exporting Your First ABAP Package via abapGit
If abapGit isn’t already installed, clone it into a temporary package using the report ZABAPGIT_FULL (instructions on the abapGit GitHub page). Once inside the UI:
- Hit “New Online Repo.”
- Paste your GitLab repo URL.
- Select Package ZDEMO_DEV.
- Press “Link and Pull.” abapGit rewrites the ABAP objects into .abap, .xml, and .json files.
- Commit and push.
Refresh GitLab and celebrate—the ABAP universe is now a first‑class Git citizen.
5 ▸ Crafting the GitLab CI Pipeline
Below is a minimal .gitlab-ci.yml that validates ABAP, lints code, and triggers a gCTS import into QA.
stages:
– lint
– build
– deploy
variables:
GCTS_API: “https://s4hana.example.com/sap/bc/cts_abapvcs/repository/ZSOL_DEMO”
AUTH: “-u GCTS_BOT:<PAT>”
lint_abap:
stage: lint
image: sapabaplint/abaplint
script:
– abaplint –config .abaplintrc
unit_test:
stage: build
image: ghcr.io/abap/test-runner:latest
script:
– abap-unit
deploy_QA:
stage: deploy
image: curlimages/curl:latest
script:
– |
curl $AUTH -X POST “$GCTS_API/pull?branch=main” -k
sleep 5
curl $AUTH -X POST “$GCTS_API/activate?branch=main” -k
when: on_success
Key points: The lint_abap stage uses abaplint for static checks; unit_test leverages the open‑source ABAP Unit runner; and deploy_QA sends HTTP POST calls to gCTS endpoints /pull and /activate. The -k flag ignores self‑signed certs in non‑prod systems—swap for company CA certificates in real landscapes.
Trigger a Git commit. Watch GitLab spin through lint, unit, deploy. Flip to the SAP GUI, run SCTS_HISTORY, and you should see transport ZSOLK900001 already imported into QA, all while you sip coffee.
6 ▸ Securing the Pipeline
Hard‑coding PATs works only for demos. In production:
- Store Git tokens in GitLab CI/CD Variables with Protected scope.
- Map the SAP service user to an external OAuth provider (Azure AD or Okta) and exchange JWTs on the fly.
- Enforce branch protection so only merge requests can trigger deploy_QA.
- Use a dedicated firewall rule allowing inbound traffic from GitLab shared runners to /sap/bc/cts_abapvcs/* and nothing else.
7 ▸ Smoke‑Testing Deployed Code
A pipeline that imports transports is half the story; you also need functional validation. Spin up UI5 Test Recorder for Fiori apps or write OPA5 test suites that assert component rendering in the browser. On the backend, schedule the ABAP Daemon Framework to execute unit tests post‑import. All results feed back to GitLab via job artifacts, turning SAP into just another column on your enterprise dashboard.
8 ▸ Observability and Rollback
Hook Prometheus to the ABAP statistics service /sap/bc/abap_monitor and visualise import durations, object counts, and dump logs in Grafana. For rollback, the mantra is simple: Git revert, gCTS activate. Snapshots of previous commits let you rewind to any point in history in under thirty seconds. Try doing that with classic co‑file and data‑file restores!
9 ▸ Real‑World Gains — A Six‑Week Case Study
A midwestern auto‑parts supplier moved from manual transports to this pipeline in six calendar weeks. By week two they committed two hundred thousand lines of legacy Z‑code to Git. Week four lit up abaplint and uncovered twelve critical SQL hints; fixing them reduced monthly DB time by seven percent. By week six the blue‑green QA landscape shipped feature packs every Friday morning. Overnight defects fell forty percent because each change bundle was small enough to reason about. The biggest surprise? Audit prep time collapsed from three weeks to four hours because Git commit hashes map one‑to‑one with business requirements—a dream for SOX.
